参数说明:
紧固范围 Range |
带宽 wide |
带厚 thick |
螺杆Screw |
|||
英制 English(in.) |
公制 Metric(mm) |
|||||
最小径 Min.Dia. |
最大径 Max.Dia. |
最小径 Min.Dia. |
最大径 Max.Dia. |
|||
0.67" |
0.75" |
17 |
19 |
18 |
0.6 |
M5×40 |
0.79" |
0.87" |
20 |
22 |
18 |
0.6 |
M5×40 |
0.91" |
0.98" |
23 |
25 |
18 |
0.6 |
M5×40 |
1.02" |
1.1" |
26 |
28 |
18 |
0.6 |
M5×40 |
1.14" |
1.22" |
29 |
31 |
20 |
0.8 |
M6×50 |
1.26" |
1.38" |
32 |
35 |
20 |
0.8 |
M6×50 |
1.42" |
1.54" |
36 |
39 |
20 |
0.8 |
M6×50 |
1.57" |
1.69" |
40 |
43 |
20 |
0.8 |
M6×50 |
1.73" |
1.85" |
44 |
47 |
22 |
1.2 |
M6×60 |
1.98" |
2" |
48 |
51 |
22 |
1.2 |
M6×60 |
2.05" |
2.17" |
52 |
55 |
22 |
1.2 |
M6×60 |
2.2" |
2.32" |
56 |
59 |
22 |
1.2 |
M6×60 |
2.36" |
2.48" |
60 |
63 |
22 |
1.2 |
M6×60 |
2.52" |
2.64" |
64 |
67 |
22 |
1.2 |
M8×75 |
2.68" |
2.87" |
68 |
73 |
24 |
1.5 |
M8×75 |
2.91" |
3.11" |
74 |
79 |
24 |
1.5 |
M8×75 |
3.15" |
3.35" |
80 |
85 |
24 |
1.5 |
M8×75 |
3.39" |
3.58" |
86 |
91 |
24 |
1.5 |
M8×75 |
3.62" |
3.82" |
92 |
97 |
24 |
1.5 |
M8×75 |
3.86" |
4.06" |
98 |
103 |
24 |
1.5 |
M8×80 |
4.09" |
4.41" |
104 |
112 |
24 |
1.5 |
M8×80 |
4.45" |
4.76" |
113 |
121 |
24 |
1.5 |
M8×80 |
4.8" |
5.12" |
122 |
130 |
24 |
1.5 |
M8×80 |
5.16" |
5.47" |
131 |
139 |
26 |
1.7 |
M10×90 |
5.51" |
5.83" |
140 |
148 |
26 |
1.7 |
M10×90 |
5.87" |
6.34" |
149 |
161 |
26 |
1.7 |
M10×90 |
6.38" |
6.85" |
162 |
174 |
26 |
1.7 |
M10×90 |
6.89" |
7.36" |
175 |
184 |
26 |
1.7 |
M10×105 |
7.4" |
7.87" |
188 |
200 |
26 |
1.7 |
M10×105 |
7.91" |
8.39" |
201 |
213 |
26 |
1.7 |
M10×105 |
8.43" |
8.9" |
214 |
226 |
26 |
1.7 |
M10×105 |
8.94" |
9.41" |
227 |
239 |
26 |
1.7 |
M10×105 |
9.45" |
9.92" |
240 |
252 |
26 |
1.7 |
M10×105 |
